INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR

INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR

    • INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR
    • INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR
    • INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR
  • INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR

    Product Details:

    Place of Origin: CHINA
    Brand Name: YUNENG
    Certification: ISO CCC
    Model Number: JFZ7908-15-10K54AD33

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: carton
    Delivery Time: 2 days
    Supply Ability: 200 per week
    Contact Now
    Detailed Product Description
    Application: LED Advertising Van Voltage And Current: 70V 150A
    Feature: Samll Size Light Weight Stable Running Package: Carton And Foam

    INVENTION PATENTED SMALL SIZE 70V 150A LED ADVERTISING VAN ALTERNATOR



    Alternators are used in modern automobiles to charge the battery and to power the electrical system when its engine is running.

    Until the 1960s, automobiles used DC dynamo generators with commuators. With the availability of affordable  silicon dioder dioderectifers, alternators were used instead. This was encouraged by the increasing electrical power required for cars in this period, with increasing loads from larger headlamps, electric wipers, heated rear windows and other accessories.



    The big power alternator and small size alternator is greatly demanded with the increasing power requirements.



    INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR

    Specification:



    Description Parameter
    rotation clockwise (viewed from the driving end)
    working temperature -40 ℃~110℃
    rated rotation speed 6000rpm,
    Max. working rotation speed 9000rpm
    unloaded speed n≤1950rpm n=6000rpm, I=150A, U≥70V
    voltage adjusting valve n=6000rpm, T=25℃, I=5A, U=70±0.8V
    temperature compensation ratio -4mV~-7mV/℃
    rectifier structure 11 tubes

    . rotation: clockwise (viewed INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATORfrom the driving end)
    2. working temperature: -40 ℃~110℃
    3. rated rotation speed: 6000rpm,
    Max. working rotation speed: 9000rpm
    4. no load speed: n≤1950rpm
    n=6000rpm, I=150A, U≥70V
    voltage adjusting valve: n=6000rpm, T=25℃, I=5A, U=70±0.8V, temperature compensation ratio: -4mV~-7mV/℃.



    Features:



    1. 2 years warranty period.

    2. more than 80% conversion efficency to save fuel.

    3. good output under the ideal speed and low speed.

    4. self excitation system is designed to the generator, thereby can connected with air conditioner directly.

    5. multi tube rectifier structure.



    INVENTION PATENTED SMALL SIZE HIGH OUTPUT 70V 150A LED ADVERTISING VAN ALTERNATOR
