QYS-12III Hydraulic truck-mounted crane with 12tons lifting capacity

QYS-12III Hydraulic truck-mounted crane with 12tons lifting capacity

    • QYS-12III Hydraulic truck-mounted crane with 12tons lifting capacity
    • QYS-12III Hydraulic truck-mounted crane with 12tons lifting capacity
    • QYS-12III Hydraulic truck-mounted crane with 12tons lifting capacity
    • QYS-12III Hydraulic truck-mounted crane with 12tons lifting capacity
  • QYS-12III Hydraulic truck-mounted crane with 12tons lifting capacity

    Product Details:

    Place of Origin: loading and delivery equipment
    Brand Name: loading lifting and delivery
    Certification: customized material handling
    Model Number: QYS-12III

    Payment & Shipping Terms:

    Minimum Order Quantity: material handling machine
    Price: truck crane
    Packaging Details: lorry crane
    Delivery Time: loader crane
    Payment Terms: truck loader
    Supply Ability: lorry loader
    Detailed Product Description
    Material: High Strength Steel Employment: Transport Industry, Construction Industry, Manufacturing Industry
    Usage: Loading And Unloading Of Freight, Lifting Wights, Lifting And Lowering Materials Other Names: Loader Crane, Lorry Crane

    The loader crane is also called truck-mounted crane or lorry crane, it is a kind of material handling machine mounted on the truck-chassis to load or unload the weights.



    There are two types of loader crane, stiff boomed or telescopic boomed and knuckled boomed, the lifting capacity is 200kg-20000kg.



    Model: QYS-12III

    working radius and lifting capacitylifting chart

    Max. Lifting capacity: 12000kgs

    Max. Lifting Moment: 360kN.m

    Max. Lifting Height: 15.2m

    Max. Working Radius: 13.5m

    Lifting capacity at different working radius: 12000/3.0, 7300/4.8, 3900/7.8, 2400/10.6, 1600/13.5

    Sections of boom: 4

    Hoist system: hook speed: 6m/min

    cable wire:Φ14×100

    motor driven, reducing by planet gear, with hydraulic brake and valve lock.

    Swivel mechanism: clockwise or counter-clockwise 360°continuous. ≤3r/min

    motor driven, reducing by planet gear, with hydraulic brake and valve lock.

    Outrigger: hydraulic,

    Hydraulic system: nominal flow rate: 80L/min

    Nominal pressure: 20MPa

    Oil tank capacity: 250L

    Safety device: with overflow valve in the hydraulic system, with balance valve and hydraulic lock for each cylinder, with auto mechanical of hydraulic brake for hoisting mechanism. Also optional over wind alarm for cable wire or prevent over wind device, optional moment protector, optional swivel limit device.
