| Place of Origin: | China |
| Brand Name: | SHIMEI |
| Certification: | MA |
| Model Number: | ZT9600/15/28D |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD4Million |
| Delivery Time: | 90 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 set per year |
| Feature: | With Backfill Function | Supporting Strength: | 0.5MPa |
|---|---|---|---|
| Working Resistance: | 6000 KN | Support Height: | Min. Height 1.5m, Max. Height 3.2m |
■ Product Features
● With the development of coal mining technology, the requirements for safety, high yield, and high efficiency in fully mechanized mining faces are increasingly higher. The issue of tunnel end and advance support has become a focus of attention for mining operators. Simultaneously, tunnel end and advance hydraulic supports are also key equipment for achieving automated working faces. The tunnel end and advance hydraulic supports developed by our factory have realized the mechanization of tunnel end and advance support. The project "Research and Design of Tunnel End Hydraulic Support for Backfill Mining Faces" completed for Xingtai Coal Mine was awarded the Third Prize for Scientific and Technological Progress by the China National Coal Association; the project "Research and Application of Tunnel End Hydraulic Support for Top-Coal Caving Mining Faces" completed for Dongpang Mine achieved safe and efficient mining in top-coal caving faces. This project has also passed the technical evaluation organized by the Hebei Province Achievement Transformation Center. Advance supports currently come in various forms such as two-column type and transverse type, meeting the personalized needs of users.
Features:
The supports must conform to the patterns of mine pressure manifestation during backfilling operations.
The supports must possess sufficient load-bearing capacity to control roof subsidence.
The supports must exhibit no weak points in their load-bearing structure.
The front and rear spaces of the supports must be independent, enabling parallel operations.
Supporting strength: 0.5MPa
Working resistance: 6000 kN
Support height: Minimum height 1.5m Maximum height 3.2m
■ Technical Parameters
|
Model
Parameter |
Tunnel End Hydraulic Support | Tunnel End Hydraulic Support | ||||
|
ZT9600/15/28D (Fully Mechanized Mining Face) |
ZT9400/30/50D (Backfill Mining Face) |
ZT6400/16/31D (Top-Coal Caving Mining Face) |
ZTC28800/17.5/35D | ZCZ32000/23/50D | ZCZ19200/20/40D | |
| Support Height (m) | 1.5-2.8 | 3.0-5.0 | 1.6-3.1 | 1.75-3.5 | 2.3-5.0 | 2.0-4.0 |
| Support Center Distance (m) | 1.75 | 2.31 | 1.46 | 2.31 | 2.1-2.9 | 2.65 |
| Working Resistance (Pa) | 9600 | 9400 | 6400 | 28800 | 2x4000 | 19200 |
| Initial Supporting Force (kN) | 7848 | 7752 | 5232 | 23280 | 2x3680 | 15696 |
| Support Strength (MPa) | 0.5 | 0.57 | 0.4 | 0.6 | 0.8 | 0.6 |
| Floor Specific Pressure (MPa) | 2.5 | 2.98 | 1.8 | 1.4 | 1.94 | 1.4 |
| Thrust/Pull Force (KN) | 989/663 | 801/528 | 663/989 | 577/364 | 801/529 | 801/528 |
| Support Advance Step (mm) | 700 | 800 | 1920 | 1700 | 800 | 1000 |
| Pump Station Pressure (MPa) | 31.5 | 31.5 | 31.5 | 31.5 | 31.5 | 31.5 |
