EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine

EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine

    • EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine
    • EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine
    • EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine
  • EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine

    Product Details:

    Place of Origin: China
    Brand Name: SHIMEI
    Certification: MA
    Model Number: EBZ160B

    Payment & Shipping Terms:

    Minimum Order Quantity: underground coal mine
    Price: coal cutting machine
    Packaging Details: excavating machine
    Delivery Time: road header
    Payment Terms: tunneling machine
    Supply Ability: coal mining
    Contact Now
    Detailed Product Description
    Small Size: The Height Is Only 1500mm Big Cutting Capacity: The Cutting Power Is 160kW
    Remote Controlled: The View Scope Is Bigger
    High Light:

    tunneling machine

    ,

    mining machine

    ,

    roadheader

    EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine



    Model

    Unit

    EBZ160B

    Total weight

    ton

    50

    Overall dimensions (L×W×H)

    mm

    10040×2800×1500

    Total power

    kW

    315.5

    Power pack power

    kW

    100

    Cutting power

    kW

    160

    Roation speed of Cutting head

    rpm

    47

    Telescopic length

    mm

    0

    Max. cutting height

    mm

    3090

    Max. positional cutting width

    mm

    4815

    Workable hardness

    Mpa

    ≤80

    Traveling speed

    m/min

    0~7.5

    Width of track shoes

    mm

    650

    Ground pressure

    Mpa

    0.136

    Loading type



    Individual star wheel

    Voltage

    V

    1140

    Gradient

    °

    ±18

    Switch of bolter



    No

    Max. part dimensions (L×W×H)

    mm

    3580×1430×1300

    weight of Max. part

    kg

    7500

    The height of the roadheader is only 1.5m,  it makes it possible to use in the 1.8m roadway. The cutting capacity can be 160kw and 200kw. The biggest tensil resistance is f=8. The roadheader is remote controlled, which enlarge the operator's view scope.

    OEM is accepted

    EBZ160B cantilever low height roadheader with 160kw cutting capacity for tunneling in the underground coal mine
