Introduction: SMJ5070TXSQ4
Chassis: Qingling Europ III
Assistant engine: Japanese Isuzu diesel engines
Two functions: road washing and sweeping, act both washer and cleaner
Application: for the washing, sweeping, water spray, cleaing of urban streets, airports, ports, bridges, squares, isolating fence, road edges, it can be applied for dust reduction by water spray.
Features:
1. Brush and high pressure flush
2. Two brooms on each side, high pressure water spray rods on both sides, double wide suck ports.
3. The left and right high pressure water spary rods is with anti-collision function, can reset automatically after avoid obstacles.
4. Full floating double wide suck ports The spray rod and the suck ports are adjustable to achieve the best cleaing result.
5. Friction clutch device to guarantee the assistant engine can start without load.
6. Hydraulic powered steering device to reduce the labour intensity.
7. High pressure, low flow rate washing method to save water, the sewage can be recollected.
8. The water circuits (high or low prssure) are controlled by electric and hydraulic.
9. High pressure water pump, nozzle, spray gun and other hydraulic and electric parts are from the international famous brands, good performace and reliable.
Specification
|
Description |
Unit |
value |
|
Overall dimensions(L×W×H) |
mm |
6450×2050×2475 |
|
Chassis model |
|
QL1070A1KAY |
|
Engine model |
|
4KH1-TCG40 |
|
Max. total weight |
kg |
7300 |
|
Curb mass |
kg |
5670 |
|
Rated weight |
kg |
1500 |
|
High pressure washing width |
mm |
3100 |
|
High prssure washing speed |
km/h |
3-15 |
|
Water pressure of high pressure |
Mpa |
10 |
|
Water flow rate of high pressure |
L/min |
70 |
|
Cleaning width |
mm |
3000 |
|
Max. capacity of water tank |
m³ |
4.5 |
|
Sewage tank capacity |
m³ |
2.8 |
